CyberCool 2

Highly customizable chiller units for data centers and industry – Made in Germany

To Contact Form

The benchmark of Free Cooling Chillers

Maximum energy efficiency and optimum reliability for complex, ambitious chiller solutions without compromise – this is what our CyberCool 2 chilled water systems stand for. And for a completely novel overall concept, whereby all the components of the CyberCool 2 are perfectly harmonized to ensure both high energy efficiency and low noise emissions. The result is a range of chillers that already meet the requirements of the Eco-design Directive 2021.

Data center

Our units are designed for highest requirements and maximum reliability

Industry

Optimized for process and industrial cooling

Free Cooling

Maximum potential savings by using cool outside air

ErP 2021 ready

Our units already meet the requirements of the Ecodesign Directive

Product Overview

At a glance

Most important benefits

TCO leader: Cooling system with the lowest total cost of ownership through Free Cooling and "Mix Mode Boost”
Flexible adaption to every project
Minimum noise emissions with maximum energy efficiency

Most important features

For medium-sized and large Data Centers, ICT sector, industry, medical, mission critical applications
Maximum possible efficiency through Indirect Free Cooling
Outdoor installation

Most important technical data

Cooling capacity (kW): 50 – 1,400

Benefits

TCO leader: Cooling system with the lowest total cost of ownership through Free Cooling and "Mix Mode Boost”
Maximum size components ensure low energy consumption
Flexible adaption to every project through 14 sizes, 5 versions, 3 designs and various options
Made and Engineered in Germany
Specially developed for mission-critical applications
Ongoing quality management during production
Minimum noise emissions with maximum energy efficiency
ErP 2021 ready

Features

For medium-sized and large Data Centers, ICT sector, industry, medical, mission critical applications
Maximum possible efficiency through Indirect Free Cooling
Safe operation at outdoor temperatures from -40 to +60 °C
Broad operating range with chilled water inlet temperatures up to +33 °C and chilled water outlet temperatures up to +22 °C
Available in 5 combinable versions:
- Free Cooling
- Adiabatic system
- Non-glycol²
- Low-GWP (R1234ze)
- Noise-optimized
Outdoor installation

Technical Data

Cooling capacity (kW)	50 – 1,400
Sizes	14
Dimensions	Length (mm): 2,300 – 12,785 Depth (mm): 1,300 – 2,300 Hight (mm): 2,350 – 2,510
Refrigerants	R410a (GWP: 2,088) R134a (GWP: 1,430) R1234ze (GWP: 7)

Climate. Customized.

From standard units to fully customized solutions

The ability to offer such a wide range to customers is the embodiment of our philosophy, "Climate. Customized.". Size, design, cooling capacity or control: STULZ’s CyberCool 2 can be precisely adapted to your individual requirements. In addition, a variety of options and equipment are available to achieve the optimum result.

Learn more about Climate. Customized.

Energy efficiency at a glance

Water chiller unit: Maximum size components ensure low energy consumption

The TCO leader

CyberCool 2 units have been specially developed for use in industry and data centers, and satisfy all efficiency and reliability requirements. The perfectly harmonized range of options, the intelligent control concept, and the option of custom-tailored solutions all combine to make the CyberCool 2 a high-end chiller with the lowest overall operating costs whatever the operating conditions.

Learn more about how to compare chillers for data center applications

1. Maximized Free Cooling coils

Reduced compressor runtime thanks to early switchover to efficient Mixed and Free Cooling mode
Minimized pump energy consumption thanks to low hydraulic pressure drops
Designed with copper and aluminum coils

2. Large microchannel condensers

Low fan energy consumption due to minimized air resistance
Low condensing temperature in DX mode for low energy consumption
Improved heat transfer combined with reduced quantities of refrigerant

3. EC fans with reduced speed

Lower nominal current and noise emissions, as the fans always run in partial load mode
Optimized for continuous operation

4. Evaporators with a large surface area for high evaporation temperatures

Low pressure drops and optimized heat transfer ensure especially high evaporation temperatures

Model overview

CyberCool 2 with screw compressors

Sizes

Cooling capacity (kW)

400 – 1,400

Dimensions

Height (mm): 2,510

Width (mm): 2,300

Depth (mm): 5,030 – 12,785

CyberCool 2 with scroll compressors

Sizes

Cooling capacity (kW)

130 – 600

Dimensions

Height (mm): 2,510

Width (mm): 2,300

Depth (mm): 3,950 – 7,250

CyberCool 2 mini with scroll compressors

Sizes

Cooling capacity (kW)

50 – 130

Dimensions

Height (mm): 2,350

Width (mm): 1,300

Depth (mm): 2,300 – 4,200

Free Cooling – maximum possible efficiency

The Free Cooling of the CyberCool 2 uses the outside temperature, which offers the greatest potential savings of all, especially in cold and temperate climates.

When outside temperatures are low, Free Cooling can completely replace energy-intensive compressor cooling. In temperate climates, the CyberCool 2 runs in energy-efficient Mixed mode for most of the year, i.e. with a mixture of Free Cooling and compressor cooling.

CyberCool 2 – Top of the class in energy:

Early switchover to Free Cooling
Maximum use of Free Cooling coils between compressor mode and Free Cooling
Coils designed to allow the maximum surface area

Free Cooling calculator
Calculate the potential of Free Cooling at your location.

No efficiency without "Mix Mode Boost"

In moderate climate zones, chillers with Free Cooling run in Mixed mode most of the year. Therefore, the greatest potential savings, by some margin, can be achieved by optimizing Mixed mode.

In Mixed mode, the outstanding performance values of the CyberCool 2 have maximum impact: it efficiently utilizes the condensation pressure control in Mixed mode to cut the energy consumption of the compressors to a minimum.

Innovation: Unlike conventional water chiller solutions, with "Mix Mode Boost" the CyberCool 2 makes 100 % use of the surfaces of the DX coils without having to regulate the fan speed. This dramatically enhances energy efficiency and slashes operating costs.

Free Cooling

At low outside temperatures, the water is cooled solely with the aid of these temperatures. Energy consumption is reduced to an absolute minimum thanks to the maximized Free Cooling coils and early, infinite switchover points.

Compressor mode

The CyberCool 2 cuts operating costs to a minimum in every operating mode, even in relatively energy-intensive DX mode: in DX mode, the CyberCool 2 achieves the best efficiency values in mission-critical applications compared with competing systems – every time.

Adiabatic system for even more Free Cooling

Benefit from the effect of adiabatic evaporative cooling. The adiabatic system with wet pads extracts heat from the outside air and increases the cooling effect. This enables the chilled water circuit to be cooled much longer via the outside air, which significantly extends the Mixed and Free Cooling mode. The result is minimum compressor running time and a reduced condensation temperature – and therefore a minimization of the operating costs.

Benefits of the adiabatic system:

Saturation efficiency 89 %
Highly efficient distribution system
Reuse of water
No water droplet entrainment (aerosol)

Non-Glycol version: Free Cooling without glycol

There are some buildings where glycol cannot be used. Therefore, with the "Non-glycol² option" glycol is now only used in the Free Cooling circuit. This option provides the benefits of Free Cooling while refraining from the use of glycol in the building.

However, by separating the Free Cooling and chilled water circuits with an additional brazed plate heat exchanger, the switchover points to Free Cooling and Mixed mode do shift by a few degrees Celsius. To be energy-efficient, the chiller must run in Mixed and Free Cooling mode as early as possible.

This unique STULZ solution keeps efficiency losses to a minimum:

Brazed plate heat exchanger with minimized pressure drops
This permits the use of a "small" Free Cooling pump with low energy consumption (must run continuously in Mixed and Free Cooling mode)
High quality, meticulously selected components

Believing is one thing – knowing is another: On the debate around glycol-free CW systems with integrated Free Cooling

When it comes to CW systems for data center cooling, many air conditioning specialists believe that it makes operational and economic sense to do away with water-glycol refrigerant in the data center interior. But more detailed analysis suggests that this theory is the exception, not the rule.

More information

The low-GWP version with R1234ze refrigerant

Units of the CyberCool 2 ze series are equipped with the refrigerant R1234ze. Due to its low global warming potential (GWP: 7), the refrigerant is particularly sustainable and classified according to the A2L class of hazardous substances. The refrigerant thus has low toxicity and low burning rate. In order to relieve operators of the underlying requirements (standard EN 378), the units are equipped with a special safety concept.

Noise-optimized version

Chilled water systems by STULZ: Powerful and quiet

Where there are people, noise emissions should always be kept to a minimum. This applies in commercial and industrial zones, and even more so in the vicinity of offices, hospitals and residential areas. The CyberCool 2 is equipped with components that lower noise emissions to a most impressive minimum.

Noise-optimized for all applications
There are many projects where the noise emissions of the chilled water systems have to be factored in. For installation near an office building or in a hospital, in particular, low noise values are essential. When designing the CyberCool 2 as a commercial water chiller, STULZ focused on optimizing noise without neglecting energy efficiency.

The CyberCool 2 is equipped with high-quality components that greatly minimize the noise level:

EC fans with a large surface area (Ø 910 mm) enable operation at reduced speed
The airflow properties ensure reduced air turbulence, resulting in low pressure drops and noise emissions
Sound-insulated compressor chamber
The fan diffuser attachment (optional) optimizes the airflow and therefore cuts electricity consumption by up to 20 % and noise by up to 5 dB(A)

The compressors, fans and pumps are the only noise sources with the CyberCool 2 units. Depending on operating conditions, the noise level of the chiller can be reduced by up to 10 dB. To do this, the maximum fan speed is restricted during operation. Furthermore, cooling capacity that is comparable with the standard version can be attained with the low-noise version due to the matching of condensers and fans.

Low-noise chillers for data centers: Peace and quiet for your cooling needs

For data centers close to residential areas, compliance with noise regulations is extremely important. Air conditioning systems can be problematic in this respect. Chillers with a cooling capacity of 500 kW, in particular, often generate a lot of noise during operation. Here, low-noise solutions from STULZ ensure the necessary noise reduction.

More information

Energy efficiency vs. low noise – Your priority in focus

Saving energy at the expense of reliability? Less noise emissions at the expense of energy efficiency? STULZ chilled water solutions make no compromises. With the CyberCool 2, the optimum operating point can be achieved for every project: Depending on priority, energy efficiency, noise emissions or both can be individually optimized. The following examples show the variable range of applications for the CyberCool 2.

Priority: Energy efficiency

The fans run at high speed.

	Sound pressure (1 m)	EER	Cooling capacity	Airflow	Fan power consumption
	74 dB(A)	3.81	760 kW	308,000 m³/h	1.63 kW

Priority: Noise emissions

Noise values are reduced to the minimum.

Sound pressure (1 m)	EER	Cooling capacity	Airflow	Fan power consumption
66 dB(A)	2.72	625 kW	123,200 m³/h	0.10 kW

Priority: Optimum noise emissions and energy efficiency

Lowest noise emissions with optimum efficiency.

Sound pressure (1 m)	EER	Cooling capacity	Airflow	Fan power consumption
70 dB(A)	3,77	735 kW	246,400 m³/h	0.83 kW

Comments:
Technical data of the CyberCool 2 ESO 7402 AHF under the following conditions:
Water 18/12 °C, outside temperature 35 °C, incl. AxiTop Noise level (full load) at a distance of 1 m in free-field conditions (to ISO 3744), 30 % glycol

Service and maintenance

As a company with locations across the globe, we offer everything you need in the extremely dynamic world of information technology – plus professional advice in the right place at the right time.

Our trained and experienced sales and service partners are located in over 140 countries. The resulting proximity to our customers allows fast response times. In addition, regular training courses and an active exchange of information ensure high quality and an extensive knowledge of all our products. This way, you can be sure your products are in the best hands and get the right maintenance – all over the world.

Locations worldwide

Options

Automatic transfer switch (more information below)
Integrated UPS
Compressor soft start
VSD pumps
Energy meter in the electrical cabinet
Corrosion protection
Axitop
Hinged Fans
Weather roof

Automatic transfer switch

Option: Second power source for the greatest possible reliability

One of the key requirements for mission-critical and sensitive applications is uninterrupted cooling – in the event of a power outage, for example. To guarantee stable cooling capacity in spite of this, STULZ provides the option of an automatic transfer switch fitted directly in the switch gear cabinet. If the primary power supply fails, this is detected automatically and the system defaults to a second power source within a minimum of 180 ms.
